- PROFESSIONAL 4K HDR MONITORING：The F7 PLUS features 4K HDMI input/output (4096x2160/60p) with 1200nits peak brightness and HDR support, delivering ultra-sharp, true-to-life colors even in bright sunlight. for cinematographers, videographers, and content creators who demand precise image quality
- INTUITIVE TOUCH SCREEN CONTROL：The 7-inch IPS touch panel (1920x1200 resolution) allows quick gesture controls for focus peaking, waveform, false color, and more—no clunky buttons needed. Streamline your workflow with one-tap access to professional tools while
- 3D LUT & ADVANCED COLOR TOOLS： camera field monitor Load custom 3D LUTs for instant color grading on-set and utilize pro features like waveform, vectorscope, histogram, and zebra patterns—essential for achieving exposure and color accuracy in films, commercials, or YouTube videos
- ALL-DAY POWER OPTIONS：field monitor 7 inch Includes external power kit (DC 7-24V input) and Type-C 5V support for flexible battery/AC power solutions. The low 15W power consumption ensures long sessions without interruption—ideal for documentaries, weddings, and live events
- COMPACT & FIELD-READY DESIGN：HDMI video monitor Weighing just 389g with 1/4-20 mounts on 3 sides, this ultra-portable monitor fits seamlessly on camera cages, tripods, or gimbals. The 160° wide viewing angle and -20°C~50°C operating range make it for outdoor shoots
7 Inch High Definition IPS Panel: With extremely high resolution 7-inch IPS panel, 1920*1200 resolution, 1200 nits brightness, 1200:1 contrast ratio and 160° viewing angle, the F7 PLUS camera field monitor provides excellent details, accurately reflect the original colors. Wide viewing clearly present more detailed image.
Sensitive Touch Control: The innovative touch control IPS panel user interface provides incredible control. You can uses simple tap and swipe gestures for the important monitoring functions without buttons.
Full Range of Auxiliary Functions: The camera video monitor supports multiple auxiliary functions, such as waveform, vector scope, histogram, peaking filter, ration marker, check field, false colors, screen marker, pixel-to-pixel, image flip, zoom-in and so on.
Screen Size: 7 inch IPS
Resolution: 1920x1200 pixels
Pixel Pitch: 0.07875 (H) × 0.07875 (W) (mm)
Aspect Ratio: 16:10
Brightness: 1200cd/m²
Contrast Ratio: 1200:1
Backlight: LED
Viewing Angle: 80°/80°(L/R) 80°/80°(U/D)
Input: HDMI 2.0, DC IN 12V, 5V Type-C, TF card slot
Output: HDMI 2.0, DC OUT 8V, 3.5mm stereo headphone interface
Input Voltage: DC7～24V
Power Consumption: 15W
Working Temperature: -20°C~50°C
Storage Temperature: -30°C~60°C
Install Way: 1/4 inch-20 Thread Socket (right, top, bottom)
Unit Size: 186x117x21(mm)
Unit Weight: 389g
Package List：
1 x Monitor
1 x Micro HDMI Cable
1 x Mounting Adapter
1 x Hexagonal Wrench
1 x Removal Wrench
1 x Users Manual(English)
Note：
